ACCU-SCOPE EXI-410 Inverted microscope

ACCU-SCOPE EXI-410 Inverted Microscope

In Stock

The New ACCU-SCOPE EXI-410 Inverted Microscope delivers outstanding optical performance, value and resolution for the study of tissue cultures and live cells in laboratories, hospitals, universities and educational institutions. With the included mechanical stage and stage plates the EXI-410 easily accommodates 96-hole well plates, tissue culture flasks, roller bottles, hemacytometers, petri dishes and 1×3″ slides.

Ease of Viewing

The EXI-410 is available in three standard configurations featuring a selection of contrast methods including brightfield, phase contrast, emboss contrast and fluorescence. All suitable to address a wide variety of applications. Each microscope is supplied with a left side camera port and the optional adapters to connect digital, HD video or low light cameras.

Compact Design, Saves Space

The compact design of the EXI-410 saves valuable countertop space in today’s crowded lab environments. Idea for phase contrast and simultaneous or stand alone fluorescence. The perfect, inexpensive research inverted microscope designed for micromanipulation and microinjection applications.

Pre-Configured Simplicity

With everything included from long working distance phase contrast objectives to mechanical stage to stage plate inserts the EXI-400s offers a safe, uncomplicated choice for modern lab managers.

Accu-Scope EXI-410 Inverted Microscope

Optional Accessories

  • NIS60 Infinity Optical System, f=200mm
  • Observation Methods: Brightfield, Phase Contrast, Emboss Contrast, Fluorescence
  • Viewing Body: Seidentopf Viewing Head, Inclined at 45°, Interpupillary 48-75mm;
  • Left-side camera port (light split with eyepieces: 100/0 and 0/100)
  • Eyepieces: EW10x/22mm, Ø30mm
  • Nosepiece: Quintuple Nosepiece
  • Objectives
    Infinity Plan Achromat 4x, 10x, 20x, 40x
    Infinity Plan Achromat Phase Contrast 4x, 10x, 20x, 40x
    Infinity Plan semi-Apochromatic 4x, 10x, 20x, 40x
    Infinity Plan semi-Apochromatic Phase Contrast 4x, 10x, 20x, 40x
  • Stage
    Flat stage 170mm(X) × 250mm(Y); 300mm wide with auxiliary stages installed
    Optional mechanical stage movement range 129mm(X) × 83mm(Y)
  • Holders
    Terasaki holder / Ø65mm petri dish holder
    Ø35mm petri dish holder
    Ø54mm petri dish holder, hemocytometer, glass slide holder
    Well clamper
    Universal holder for Terasaki plate holder, glass slide, Ø35-65 dish
    and hemocytometer
    Ø90mm petri dish holder
  • Condenser
    Extra-long working distance condenser, WD 75mm, NA 0.3
  • Slider
    Universal phase contrast slider 4x/10x, 20x, 40x
  • Stand
    Cast aluminum alloy
  • Illumination
    3W S-LED Light
  • Fluorescence
    3W LED lights (UV: 365nm or 405nm, Blue; 485nm, Green: 525nm or 560nm)
    3-position filter cube turret
  • Focusing
    Coaxial coarse and fine focus; fine-focus precision 0.002mm;
    focus range: 7mm up, 1.5mm down; total travel limit 18.5mm
  • Accessories
    Camera adapters; eyepieces, reticles, micrometers; IF550nm green filter;
  • Dust cover; Centering telescope
  • Dimensions (LWH)
    543mm x 243mm x 470mm (563mm x 243mm x 470mm
    with fluorescence configuration)
  • Warranty
    5-year limited warranty for parts, labor and electronic components.
    1-year warranty on LED bulbs
  • 0.35x, 0.5x, 0.65x and 1.0x adjustable C-mount adapters
