Accu-Slide MS

The ACCU-Slide MS manual scanning solution features easy to use, auto-stitching software coupled with a high-speed USB 3.0 camera. Stitch large panoramic images in minutes. Perfect for brightfield and polarized light samples!

Optical Excellence

This is an affordable, convenient and flexible solution to all your digital slide-scanning needs! At a fraction of the cost of a slide scanner, the ACCU-Slide MS software uses your existing microscope. Our intuitive software and the matching high-speed camera enable users to scan as little or as much of an entire slide as is needed, resulting in high resolution images for documentation, analysis and more!

With the ACCU-Slide MS software automatic stitching occurs as the stage moves.  Complete with built-in shading correction, color balance, focus indicator and thumbnail overview of the scanning process. It even permits users to scan noncontiguous specimens with its “freeze feature.” Whether you need just a few fields or and an entire sample, this manual slide scanning solution is worth a look!

Now available for use with fluorescence samples and polarized light birefringent thin sections!



(281) 579-0342

Specifications

Model 2.3 MP Color Camera
Sensor / Model CMOS / Sony IMX249
Sensor Size 11.3mm x 7.1mm; 1.0x camera adapter (recommended)
Image Transmission High-speed
Pixel Size 5.86µm x 5.86µm
Resolution 1920 (H) x 1200 (V) pixels
Frame Rate 41FPS
Shutter Mode Global
Exposure Control ACCU-SlideMS Software
Pixel Bit Depth 10 or 12
Operating Temperature 0-50%
Camera Size & Weight 29.3mm x 29mm x 29mm / 80g
Data Interface USB 3.0, compatible with USB 2.0
Power Requirements & Consumption Via USB 3.0 interface; 2.7 watts
Computer System Requirements Recommended: Intel Core i5 or i7 Quad Core 4000/6000/7000 Series Processor
16 GB RAM, 512 GB Solid State Hard Drive, Intel 100 Series H170/Z170 . . . Or Intel 200 Series Chip Set
Windows 10 Professional, 64-bit OS
Display 23″ Display 1920 x 1080 pixels (good)
27″ Display 2560 x 1440 pixels (better)
32″ Display 3850 x 2160 pixels (best)
Warranty 1 year
