Jenoptik Digital Cameras // Meyer Instruments

Jenoptik has the best digital cameras for your microscope applications. PERIOD.

ProgRes® microscope cameras are designed for perfect image acquisition. GRYPHAX software provides extended depth of field (EDF) imaging, mosaic tiling, realtime histograms, realtime image shading, side by side viewing and so much more!

The high-grade ProgRes® camera line, consisting of CMOS and CCD cameras for a wide range of light-microscopic and macroscopic applications in science and industry, benefits from Jenoptik’s decades of experience in developing and manufacturing of internationally renowned products for high-end digital imaging. THEIR CAMERAS ARE AS GOOD AS IT GETS!

(281) 579-0342

Jenoptik Digital Cameras – CMOS

PROGRES SUBRA

ProgRes ® Gryphax SUBRA, 1080p HD Color Digital Camera, Full HD 1920x1080, 30 fps, record at video speed, USB3 interface, no external power supply required, on-off switch, 2/3” sensor 5.5 x 5.5 um, 2048 x 1084 pixels, 12 bit, 4096 grey scales, Exposure times from 52 us-2 seconds, Progressive scan, Global shutter, Precise reproduction of extremely fine details and color nuances also in lights and shades, No color fringing, moiré effect or blooming, High dynamic range allows reproduction of extremely dark and bright, Live-image optimized – all features in real time, all the time, Gryphax® Software can be operated on Windows PC as well as Apple Macintosh operating systems, 2 year warranty!

PROGRES ARKTUR

ProgRes ® Gryphax ARKTUR, Color Digital Camera, Full 8 MPixels, 50 fps at 2.1 Mpixels, 50 fps, at full HD, USB3 interface, no external power supply required, on-off switch, 2/3” sensor 2.4 x 2.4 um, 2.1, 8 Mpixels, 10 bit, 1024 grey scales, Exposure times from 52 us-10 seconds, Progressive scan, Global shutter, Precise reproduction of extremely fine details and color nuances also in lights and shades, No color fringing, moiré effect or blooming, High dynamic range allows reproduction of extremely dark and bright, Live-image optimized – all features in real time, all the time, Gryphax® Software can be operated on Windows PC as well as Apple Macintosh operating systems, 2 year warranty!

PROGRES NAOS

ProgRes ® NAOS , Color Digital Camera, Full 19.4 MPixels, 50 fps at 2.1 Mpixels, 30 fps at 4.8 Mpixels, USB3 interface, no external power supply required, on-off switch, 1” sensor 2.4 x 2.4 um, 2.1, 4.8, 19.4 Mpixels, 12 bit, 4096 grey scales, Exposure times from 52 us-10 seconds, Progressive scan, Global shutter, Precise reproduction of extremely fine details and color nuances also in lights and shades, No color fringing, moiré effect or blooming, High dynamic range allows reproduction of extremely dark and bright, Live-image optimized – all features in real time, all the time, Gryphax® Software can be operated on Windows PC as well as Apple Macintosh operating systems, 2 year warranty!

Jenoptik Digital Cameras – CCD

SpeedXT Core 5

Image Sensor: 2/3″ CCD Sensor Resolution (max): 2580×1944 pixels (5.0 MP) Active Sensor Size: 9.04mm x 7.86mm Max Frame Rate: 13 fps (2580×1944), 45 fps (640×484) Dynamic Range: 61 dB Analog Gain: 1x…5x Dimensions (LxWxH): 89mm x 84mm x 93mm) Weight: approx. 700g

C14 Plus

Image Sensor: 2/3″ CCD progressive scan Sensor Resolution (max): 1360×1024 pixels (1.4-12.5 MP) Active Sensor Size: 8.8mm x 6.6mm Max Frame Rate: 13 fps (1360×1024), 51 fps (680×512) Dynamic Range: 67 – 69 dB Analog Gain: 1x…8x Dimensions (LxWxH): 89mm x 84mm x 93mm) Weight: approx. 800g

MF Cool

Image Sensor: 2/3″ CCD progressive scan Sensor Resolution (max): 1360×1024 pixels (1.4-12.5 MP) Active Sensor Size: 8.8mm x 6.6mm Max Frame Rate: 13 fps (1360×1024), 51 fps (680×512) Dynamic Range: 67 – 69 dB Analog Gain: 1x…8x Dimensions (LxWxH): 145mm x 93mm x 123mm) Weight: approx. 800g

CF Cool

Image Sensor: 2/3″ CCD progressive scan Sensor Resolution (max): 1360×1024 pixels (1.4-12.5 MP) Active Sensor Size: 8.8mm x 6.6mm Max Frame Rate: 13 fps (1360×1024), 51 fps (680×512) Dynamic Range: 67 – 69 dB Analog Gain: 1x…8x Dimensions (LxWxH): 145mm x 93mm x 123mm) Weight: approx. 800g

Call today to arrange a web based demonstration! We have all microscope types available for use with virtually any sample.

(281) 579-0342

JENOPTIK Website

Meyer Instruments, Inc., is an authorized JENOPTIK dealer-reseller.
