Promicra PRO MLS

Promicra PRO-MLS Heavy  Duty Stand

PRO-MLS is universal heavy-duty motorized stand suitable for wide range of microscopic and macroscopic Z stacking applications.

Promicra PRO-MLS

Promicra Pro MLS Stand
Promicra Pro MLS Stand
Promicra Pro MLS with 76mm diameter holder
Promicra Pro MLS with 76mm diameter holder
Promicra PRO MLS stand, and CB-ZM control unit
Promicra PRO MLS stand, and CB-ZM control unit showen with sample stereomicroscope

Features Overview

  • Motorized Z axis (travel and focusing)
  • Focusing and travel by UP and DOWN buttons, change of focus speed using SPEED button
  • Adapters for various optical devices (stereomicroscopes, macro cameras…) and accessories (X-Y stages, LED illuminators…)
  • Compatible with backlight LED illuminators for transmitted illumination e.g. Schott VisiLED
  • High bearing capacity (up to 16 kg) and rigidity, silent running
  • Travel range 19.5 cm
  • Travel protected by built-in limit switches. Vertical position of lower limit switch adjustable
  • Minimal step 15 um
  • Remote control by a two button foot switch (optional)
  • Controlled by CB-ZM control unit with PC control option
  • Compatible with Deep Focus Extended Depth of Field (EDF) software module for QuickPHOTO software.
  • Suitable also for macro applications
  • Motorized column can be detached from the base and mounted e. g. to a desk or a table by 6 screws.

Available Microscope Adapters

  • PRO-FUAD Adapter (adapter with 32 mm mounting rod)
  • PRO-FUAD Adapter + SZ2-STS Focusing Arm with 76 mm Mounting Diameter (yoke)
  • PRO-ZBAD Adapter for Mounting of Olympus SZX/SZX2 Stereomicroscopes without Focusing Unit

Examples of Compatible Microscopes

  • OLYMPUS® SZX and SZ series stereomicroscopes
  • Nikon® SMZ1270, SMZ1270i, SMZ800N, SMZ745/745T, SMZ445/SZ460
  • Leica® S6E,S6, M50, M60, M80, S8APO, MZ10F
  • Huvitz® HSZ-700 and HSZ-600 series stereomicroscopes
  • Motic® SMZ series streomicroscopes (with 76mm mounting diameter)
  • All other microscopes attachable to 32 mm rod or microscopes with 76mm mounting diameter (yoke)
