Metkon Servocut 302 Automatic Abrasive Cutting Machine
Small Footprint, Large Cutting Capacity
Powerful Cutting Motor!
Servocut 302
Automatic Abrasive Cutting Machine
Programmable with 7″ HMI touch screen control, with Siemens PLC control unit, with automatic chop cutting and automatic table-feed cutting systems, with various cutting methods, programmable with colored LCD display of cutting parameters, accurate and motorized positioning of the specimen in X – Y and Z axis (X-axis for plane parallel cutting is optional), ergonomic joystick with adjustable speed control, integrated feed path control, power dependent adjustable feed rate, variable cutting force, pulse cutting mode, bar graph overload display, powerful 4 kW cutting motor, with variable cutting speed 600-4000 rpm, with electronic brake system, cutting capacity up to 110/90 mm solid stock, with cut-off wheels up to ø300/250mm, twin T-slotted table(Y-direction only) made of stainless steel, bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings,
with extra advanced cutting methods: “Rapid Pulse Cutting, Table Oscillation Cutting, Instafeed Cutting, Automatic Chop Cutting, Automatic Table Feed Cutting, Joystick Cutting” Ready for operation.
Without clamping devices, without recirculation cooling tank.
Includes a standard set of cutting consumables composed of;
*An assortment of 20 cut-off wheels with 300 mm dia.
*5 lt of Metcool cooling fluid.
400 V, 3 phase, 50/60 Hz.
| ORDER NO | 15 57 | 15 57-AX |
| MODEL NO | SERVOCUT 302-AA | SERVOCUT 302-AA-AX |
| Max. Wheel Diameter | 300 mm | 300 mm |
| Max. Cutting Capacity, Circular | 110 mm | 110 mm |
| Max. Cutting Capacity, HxD | 70×200 mm | 70×200 mm |
| Z-Axis Travel, (mm) | 125 | 125 |
| Y-Axis Travel, (mm) | 220 | 220 |
| X-Axis Travel, (mm) | – | 95 |
| T-Table Dimension, (mm) | 444×275 | (395+95)x275 |
| T-Slot Dimension, (mm) | 12 mm | 12 mm |
| Cutting Motor Power (S1) | 4 kW | 4 kW |
| Wheel Speed, RPM | 600-4000 | 600-4000 |
| Cutting Feedrate, (μm/s) | 20-5000 | 20-5000 |
| HMI Touch Screen | 7 inch | 7 inch |
| Chop Cutting, Z- Axis | Auto | Auto |
| Table Feed Cutting, Y-Axis | Auto | Auto |
| Parallel Cutting, X-Axis | Auto | Auto |
| Table Oscillating Cutting | Standard | Standard |
| Rapid Pulse Cutting | Standard | Standard |
| Smart Feed Control | Standard | Standard |
| StepCut; Segment Cut; Diagonal Cut | Optional | Optional |
| Size WxDxH, (cm) | 94x99x76 | 94x99x76 |
| Weight | 250 kgs | 250 kgs |
| Recirculation Cooling Unit | 80 lt | 80 lt |
